Notor 65 Delta

Installation

Single or continuous installation via wire suspension or surface mounted. Installation via wire suspension requires wire brackets which provide flexible c/c, see accessories. Can also be wall mounted with special brackets, see Accessories.

Connection

The luminaire is equipped with an access hole for cabling on the top. A special short end with cable entry is used for a surface mounted mains cable, see Accessories. The luminaire unit is equipped with a through-wiring cable (5x1.5 mm²) and a snap-in connection in each end-cap. In a continuous installation, the luminaire row should always begin with a start luminaire. The illuminated corners can be used as a start luminaire and are equipped with through-wiring and quick connection in one end. If creating a closed system one of the corner needs to be used as a start.

Design

Luminaire body enameled in white (RAL 9016 G40) alternatively black (RAL 9005 G30) or natural anodised extruded aluminium finish. The indirect light is covered by an opal film which generates a wide beam and acts as a dust cover. End caps are included in the Start- and Single-luminaire.

Louvre

Delta – microprism louvre in acrylic (PMMA.

Emergency lighting

There is a unit with integrated emLED available for Notor 65, see Accessories.

Dimming

CLO (Constant Light Output) and DALI/Phase-pulse control as standard. Suffix number -449, -533, -539, -554 and -555 only refer to single luminaires.
Phase pulse control is available with Push Dim and Pull-cord dimming.
e-Sense Active – PIR sensor with presence and daylight control via DALI.
Organic Response – PIR sensor with presence and daylight control. All luminaires have master/slave functionality with IR communications. Suffix number -533 only refer to single luminaires.

Unit for Organic Response lighting control ordered separately, see accessories. The Organic Response unit is connected as a start luminaire, with a maximum of 2 luminaires connected to each side. To include end-caps, one of the luminaires should be a start luminaire and the other continuous. See assembly instructions for more information.

Accessories

Assembly fittings and supplementary components, see Accessories.

Miscellaneous

For 1200 30/70, 1200 Tunable white direct/indirect and 1700 direct/indirect, there are two DALI addresses per luminaire. For 2400 direct/indirect luminaires, there are also two DALI addresses per luminaire, where one DALI address controls the direct/indirect light on the first 1200 module and the other DALI address controls the other 1200 module.

CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.

The LEDs are protected against contact.

To calculate how many luminaires and accessories you will need to complete a run, please use our configurator.
